Screwed Pneumatic Angle Sheet Valves

Screwed Pneumatic Angle Sheet Valves

Screwed Pneumatic Angle Sheet Valves are industrial flow control devices designed to regulate, control, or shut off the flow of liquids, gases, or steam in pipelines using compressed air (pneumatic power). These valves operate through a pneumatic actuator that drives the valve piston or diaphragm to open or close the passage of media.

Built with a screwed (threaded) end connection, these valves are easy to install in pipelines without welding. The Angle Sheet design allows a smooth 90-degree flow path, reducing pressure loss and ensuring quick response with minimal wear.

These valves are widely used in industries where automated, fast, and leak-proof flow control is essential for handling air, water, steam, oils, chemicals, or other fluids.

Applications of Screwed Pneumatic Angle Sheet Valves

Used In:

• Chemical & Petrochemical Industries
• Food & Beverage Processing Plants
• Pharmaceutical & Biotech Industries
• Textile & Dyeing Units
• Water Treatment Plants
• Oil & Gas Industries
• HVAC Systems
• Pneumatic Automation Systems
• Steam & Condensate Control
• Packaging & Filling Machines

Features of Screwed Pneumatic Angle Sheet Valves

• Robust Construction with Stainless Steel / Brass / Gunmetal Body
• Screwed (Threaded) End Connections for Easy Installation
• Angle Type Design for Minimum Pressure Loss
• Pneumatic Actuator for Fast Opening & Closing
• Suitable for Air, Water, Steam, Gas, Oil & Chemicals
• Compact Design with High Flow Rate
• Long Life Cycle with Low Maintenance
• Available in Normally Closed (NC) or Normally Open (NO) Types
• Temperature & Pressure Resistant Design
• Leak-Proof Performance with High Sealing Efficiency

Uses of Screwed Pneumatic Angle Sheet Valves

• Controlling Liquid or Gas Flow in Pipelines
• Steam Regulation in Industrial Applications
• Automatic Water or Air Shut-off Systems
• Pressure & Flow Management in Processing Lines
• Industrial Automation for Fluid Control
• Protection of Equipment from Overpressure
• Efficient Flow Direction Control
• Fast & Accurate Opening & Closing of Media Flow
• Application in Process Control Panels
• Fluid Isolation or Mixing in Batch Processing

Top 10 FAQs on Screwed Pneumatic Angle Sheet Valves

Q1. What is a Screwed Pneumatic Angle Sheet Valve?

It is a pneumatically operated flow control valve with screwed ends designed to control or shut off fluids like air, water, steam, oil, or chemicals at a 90-degree flow angle.

Q2. Where are these valves used?

These valves are commonly used in industries like chemicals, pharmaceuticals, food processing, steam handling, and automated control systems.

Q3. What is the advantage of the Angle Type Design?

The angle design ensures a smooth, fast flow with minimal pressure drop and compact installation in confined spaces.

Q4. What media can a Screwed Pneumatic Angle Sheet Valve handle?

These valves handle compressed air, water, steam, oil, gas, and various chemical fluids.

Q5. What sizes are available in these valves?

They are available in various sizes ranging from ½ inch to 2 inches (or customized sizes based on requirements).

Q6. How is the valve controlled?

The valve is operated by a pneumatic actuator using compressed air supply, ensuring fast and reliable control.

Q7. What materials are used for the valve body?

Mostly Stainless Steel (SS304 / SS316), Brass, or Gunmetal is used for the valve body for durability and corrosion resistance.

Q8. Can these valves be used for steam applications?

Yes, Screwed Pneumatic Angle Sheet Valves are highly suitable for steam flow control due to their heat-resistant design.

Q9. Are these valves available in Normally Closed & Normally Open types?

Yes, based on process needs, they are available in both NC (Normally Closed) and NO (Normally Open) types.

Q10. What are the main benefits of using Pneumatic Angle Sheet Valves?

• Quick Operation
• Compact Design
• Reliable Flow Control
• Low Maintenance
• Easy Installation
• Durable & Leak-Proof Performance
