Sheet Type Pneumatic Valve Exporter in India

Sheet Type Pneumatic Valve Exporter in India

Description:

A Sheet Type Pneumatic Valve is a compact, precision-engineered control device used to regulate the flow of air, gas, or other media through flat or sheet-like channels in automation systems. Unlike conventional valve bodies, these valves are designed with a flat sheet structure, making them ideal for space-saving installations in modular pneumatic circuits, machines, and compact control panels.

Indian exporters offer these valves in 2/2, 3/2, 4/2, and 5/2 configurations, widely accepted in global automation, packaging, and manufacturing industries due to their durability, interchangeability, and low power actuation.

How It’s Made:

1. Design & Body Construction:

   • The valve housing is created from anodized aluminum, brass, or stainless steel sheet plates using CNC laser cutting or stamping.

   • Flat layout allows for manifold mounting or inline use with minimal footprint.

2. Sealing & Valve Seat Fabrication:

   • High-precision PTFE, nitrile, or Viton seals are used to ensure zero leakage under pneumatic pressure.

   • Valve seat is milled into the sheet to control the open/close action of ports.

3. Spool or Poppet Mechanism:

   • A spool or poppet-type actuator regulates the flow between inlet and outlet passages.

   • Connected to a solenoid coil or air piston that shifts the mechanism.

4. Solenoid & Coil Mounting (for solenoid-operated types):

   • Compact 24V/110V/230V AC or DC coils are mounted with DIN connectors.

   • Manual override or LED indicator available.

5. Testing & Assembly:

   • Each valve undergoes pressure tests, leak tests, and switching cycle endurance before export.

Where It’s Used:

• Industrial Automation Systems

• Filling, Dosing, and Packing Machines

• Food & Pharma Machinery

• CNC & Robotic Systems

• Air-Operated Door/Clamping Mechanisms

• Textile & Plastic Machinery

• Vehicle-Mounted Pneumatic Control Panels

Key Features:

• Compact Sheet Design for Tight Spaces

• Available in 3/2, 5/2, 5/3 Valve Logic

• Solenoid or Pilot Operated

• Voltage Options: 24V DC, 110V/230V AC

• Working Pressure Range: 2 to 10 bar

• Mounting: Sub-plate, Manifold, Inline

• Manual Override for Emergency Actuation

• Cycle Life: 10+ Million Operations

Importance:

Sheet-type pneumatic valves are crucial in machines where space, precision, and response time are critical. Their modular flat design makes them ideal for use in compact control circuits, replacing bulky round-body valves in many applications.

Advantages:

• Quick Response Time (Less than 30ms)

• Highly Customizable Flow Paths

• Silent, Low-Vibration Operation

• Easy Integration in Control Panels & Manifolds

• Low Energy Consumption for Coil Operation

• Long Life Cycle – Ideal for Continuous Use

• Suitable for OEMs & Global Automation Systems

Significance in Export Markets:

Indian exporters are meeting international demands with ISO/CE-certified valves, providing reliable, high-precision pneumatic control solutions to countries across Europe, Africa, the Middle East, and Southeast Asia. These valves play a significant role in modern industrial automation systems globally.

Sheet Type Pneumatic Valve Price Range (India – Export Ready):

FAQs:

Q1. What media can be controlled with sheet type valves?
A: Primarily compressed air, but also suitable for neutral gases, vacuum, or filtered dry air.

Q2. Can I use them with PLC-based automation?
A: Yes, they are fully compatible with PLC and relay-based systems, especially the solenoid-operated variants.

Q3. What’s the minimum order quantity (MOQ) for exports?
A: Most Indian suppliers offer MOQ from 25–100 units, depending on valve type.

Q4. Are they RoHS or CE compliant?
A: Yes. Many exporters provide RoHS, CE, and ISO 9001 certified valves.

Q5. Do they support customization?
A: Absolutely. Exporters in India can offer custom ports, colors, coil voltage, branding, and manifold layouts.

Conclusion:

Sheet Type Pneumatic Valves are a compact, reliable, and efficient solution for modern pneumatic control systems. Indian exporters offer cost-effective, precision-manufactured, and globally compliant valves that meet the demands of automation, packaging, and material handling systems worldwide. With robust quality control and customization capability, these valves are ideal for OEMs, panel builders, and automation integrators across the globe.

Contact:-9687876793

Gmail:-tridentflowcontrol5456@yahoo.com

Website:-https://tridentflowcontrols.com/
